Send Email🖨️ Sublimation & Billboard Digital Printing Machine
🔬 Working Principle
This industrial-grade printer is designed for high-speed sublimation and disperse ink printing. Sublimation printing works by converting solid ink into gas under heat, allowing it to penetrate polyester-based surfaces and solidify within the fibers—resulting in permanent, washable, and high-resolution prints.
Billboard printing, on the other hand, uses disperse inks for direct application onto wide-format media, ideal for outdoor signage and large-scale textile graphics. The machine supports jumbo roll paper handling, enabling uninterrupted production for high-volume operations.
⚙️ Technical Specifications
| 🔧 Feature | 📐 Details |
|---|---|
| Print Speed | Up to 560 m²/hour |
| Print Widths | 2050 mm / 3200 mm |
| Printheads | Kyocera KJ4B or Konica Minolta 1024i |
| Number of Printheads | 8 / 12 / 16 |
| Color Configuration | 4, 6, or 8 colors (CMYK + LC/LM + Fluorescent options) |
| Ink Types | Sublimation / Disperse |
| Control System | PLC-based automation |
| Pre-Drying System | Halogen resistance heaters |
| Print Resolution | Up to 1200 DPI |
| Auto Cleaning | Magnetic sensors + air compressor system |
| RIP Software | Caldera (ICC profile support, color management, optimization) |
| Power Requirements | Main Feed: 220V (±10%) / 25A<br>Pre-Dryer: 220V (±10%) / 80A |
| Machine Dimensions (with Fixation) | 520 cm x 210 cm x 150 cm |
| Machine Dimensions (without Fixation) | 5000 mm x 1500 mm |
| Air Pressure Requirement | 0.6 MPa @ 2L/min |
| Net Weight | 2500 kg |
| Paper Handling | Industrial jumbo roll – over 1000 kg per roll |
🎯 Application Areas
-
🧵 Textile: Sportswear, flags, curtains, scarves, home textiles
-
📄 Advertising: Billboards, banners, event graphics
-
🖼️ Decoration: Canvas prints, wall coverings, interior graphics
-
📦 Promotional: Bags, pillows, personalized products
🚀 Advantages
-
⚡ High-speed output: Up to 560 m²/hour for mass production
-
📏 Wide-format capability: 2.5 m and 3.2 m options for large designs
-
💧 Permanent prints: Washable, UV-resistant, and durable
-
🔄 Flexible production: Suitable for both textile and signage sectors
-
🧼 Low waste: Digital workflow minimizes material loss
-
🎨 Customization: No screens or plates needed—each print can be unique
A high-performance industrial printer designed for sublimation and disperse ink applications on wide-format media. Ideal for textile and billboard production with jumbo roll paper handling.
⚙️ Technical Specifications
| 🔧 Feature | 📐 Details |
|---|---|
| Printing Speed | Up to 560 m²/hour |
| Printing Widths | 2050 mm / 3200 mm |
| Printheads | Kyocera KJ4B or Konica Minolta 1024i |
| Number of Printheads | 8 / 12 / 16 |
| Color Configuration | 4, 6, or 8 colors |
| Ink Types | Sublimation / Disperse |
| Control System | PLC-based automation |
| Pre-Drying System | Halogen resistance heaters |
| Print Resolution | Up to 1200 DPI |
| Auto Cleaning | Magnetic sensors + air compressor system |
| RIP Software | Caldera |
| Power Requirements | Main Feed: 220V (±10%) / 25A<br>Pre-Dryer: 220V (±10%) / 80A |
| Machine Dimensions (with Fixation) | 520 cm x 210 cm x 150 cm |
| Machine Dimensions (without Fixation) | 5000 mm x 1500 mm |
| Air Pressure Requirement | 0.6 MPa @ 2L/min |
| Net Weight | 2500 kg |
| Paper Handling | Industrial jumbo roll – over 1000 kg per roll |
🎯 Application Areas
-
🧵 Textile sublimation printing
-
📄 Billboard and large-format signage
-
🖼️ Soft signage, flags, home textiles
-
📦 Continuous roll production with minimal downtime
