ALUMINUM FEED WIRE (AL WIRE)
HIGH PURITY ALUMINUM WIRE / ALUMINUM WIRE
1. PRODUCT IDENTIFICATION AND CHEMICAL IDENTITY
| Parameter | Information |
|---|---|
| Product Name | Aluminum Feed Wire |
| Chemical Name | Aluminum Wire, High Purity Aluminum Wire |
| Other Names | Al Wire, Aluminum Feed Wire, Alloy Wire Additive, Wire Form Aluminum, High Purity Al Wire |
| Chemical Composition | Al (Minimum 99.5% purity) |
| CAS Numbers (Component Based) | Aluminum (Al): 7429-90-5, Iron (Fe): 7439-89-6, Silicon (Si): 7440-21-3, Zinc (Zn): 7440-66-6 |
| Appearance | Silver-gray metallic wire |
| Odor | Odorless |
| Physical State (20°C) | Solid (metallic) |
2. CHEMICAL STRUCTURE
2.1. Molecular Structure
Aluminum feed wire is produced from high purity (minimum 99.5%) aluminum. Aluminum has an FCC (Face-Centered Cubic) crystal structure. The wire form is designed for controlled aluminum addition in automatic feeding systems and alloy blending operations. High purity prevents unwanted impurities from entering the alloy.
Structural Features:
ALUMINUM FEED WIRE (Al Wire)
|
Al FCC Crystal Structure
|
+----------------+----------------+
| | |
High Purity Precision Suitable for
(99.5%+ Al) Diameter Automatic
Tolerances Feeding
2.2. Structural Properties
| Parameter | Value |
|---|---|
| Crystal Structure | FCC (Face-Centered Cubic) |
| Purity | Minimum 99.5% Al |
| Density | ~2.7 g/cm³ |
| Melting Point | ~660 °C |
| Appearance | Silver-gray metallic wire |
| Physical Form | Wire (Coil or cut lengths) |
3. COMMERCIAL VARIANTS AND COMPOSITIONS
3.1. Aluminum Wire Diameter Options
| Variant | Diameter | Tolerance | Description |
|---|---|---|---|
| Al Wire Ø9.5 mm | 9.5 mm | ±0.1 mm | Standard feed wire diameter |
| Al Wire Ø12.5 mm | 12.5 mm | ±0.1 mm | Larger diameter for higher feed rates |
3.2. Typical Chemical Composition
| Element | Content |
|---|---|
| Aluminum (Al) | ≥ 99.5% |
| Iron (Fe) | ≤ 0.30% |
| Silicon (Si) | ≤ 0.15% |
| Zinc (Zn) | ≤ 0.05% |
| Other Total Impurities | ≤ 0.10% |
4. PHYSICAL AND CHEMICAL PROPERTIES
| Property | Value | Description |
|---|---|---|
| Appearance | Silver-gray metallic wire | - |
| Odor | Odorless | - |
| Chemical Purity | ≥ 99.5% Al | - |
| Density | ~2.7 g/cm³ | - |
| Melting Point | ~660 °C | - |
| Electrical Conductivity | High | Characteristic of pure aluminum |
| Solubility in Water (25°C) | Insoluble | - |
| Solubility in Acids | Soluble | Releases hydrogen gas |
| Physical Form | Wire | Coil or cut lengths |
| Packaging | Coiled on spools, bundled rods, shrink wrap or boxes | - |
5. STABILITY AND REACTIVITY
| Parameter | Information |
|---|---|
| Chemical Stability | Stable under normal conditions; forms a passive oxide layer on the surface. |
| Conditions to Avoid | Oxidizing atmosphere at high temperatures, strong acids, moisture. |
| Incompatible Materials | Strong acids, strong bases, oxidizing agents. |
| Hazardous Decomposition Products | Upon oxidation at high temperatures: aluminum oxide (Al₂O₃). |
| Hazardous Polymerization | Will not occur. |
| Hygroscopicity | Low; does not absorb moisture under normal conditions. |
5.1. Chemical Reactions
-
Oxidation (at High Temperature):
4Al + 3O₂ → 2Al₂O₃ -
Reaction with Acids:
2Al + 6HCl → 2AlCl₃ + 3H₂↑
6. APPLICATION AREAS
6.1. Alloy Production and Blending
| Application | Function | Details |
|---|---|---|
| Alloy Blending | Base metal or diluent | Used in aluminum alloy production |
| Master Alloy Dilution | Controlled Al addition | Diluting master alloys to desired composition |
| Automatic Wire Feeding | Dosing | Precise Al input in automatic feeding systems |
6.2. Sectoral Applications
| Application | Sector |
|---|---|
| Alloy Blending and Casting | Automotive |
| High Purity Alloy Systems | Aerospace |
| Additive in Structural Aluminum Profiles | Construction |
| Master Alloy Production | Metallurgy |
| Thermal and Conductive Alloys | Electrical/Electronics |
6.3. Sectoral Suitability Table
| Sector | Suitability | Explanation |
|---|---|---|
| Automotive | Suitable | Used in alloy blending and casting |
| Aerospace | Suitable | In high purity alloy systems |
| Construction | Suitable | Additive in structural aluminum profiles |
| Metallurgy | Suitable | Primary input in master alloy production |
| Electrical/Electronics | Suitable | Used in thermal and conductive alloys |
| Food Packaging | Limited | Food contact certification required |
7. STANDARDS AND COMPLIANCE
| Standard | Description |
|---|---|
| EN 573 | European aluminum alloy standards |
| ASTM B233 | American aluminum wire standards |
| ISO 209 | International aluminum standards |
8. ALTERNATIVE / SUBSTITUTE PRODUCTS
| Alternative | Description | When to Use |
|---|---|---|
| Al Wire Ø9.5 mm | Standard diameter | Common automatic feeding systems |
| Al Wire Ø12.5 mm | Large diameter | Systems requiring high feed rates |
| Aluminum Ingot | Ingot form | Manual blending, not suitable for automatic feeding |
| Aluminum Granule | Granule form | Small-scale production |
| Aluminum Chip | Chip form | Low-cost applications, lower efficiency |
9. SAFETY AND TOXICOLOGY
| Parameter | Value |
|---|---|
| Acute Oral Toxicity (LD50, Rat) | > 2,000 mg/kg (low toxicity) |
| Dermal Toxicity | Low |
| Skin Irritation | Mild irritant |
| Eye Irritation | Mild to moderate irritant |
| Inhalation | Metal dust inhalation may cause respiratory tract irritation. |
| Carcinogenicity | Not classified as carcinogenic. |
| Mutagenicity | Not mutagenic. |
| Chronic Effects | Long-term data on aluminum compounds is limited. |
| Environmental Hazards | Low aquatic toxicity. |
9.1. GHS Classification
| Hazard Class | Category | H-Statement |
|---|---|---|
| Flammable Solid (Metal Dust) | Category 1 | H228: Flammable solid. |
| Skin Irritation | Category 2 | H315: Causes skin irritation. |
| Eye Irritation | Category 2A | H319: Causes serious eye irritation. |
| Specific Target Organ Toxicity | Category 3 | H335: May cause respiratory irritation. |
Signal Word: WARNING
Hazard Pictograms: GHS02 (Flame), GHS07 (Exclamation Mark)
10. STORAGE AND SHELF LIFE
| Parameter | Condition |
|---|---|
| Storage Conditions | Store in a cool, dry, and well-ventilated area. |
| Container Requirements | Dry, moisture-free environment; store in original packaging. |
| Temperature | Room temperature (15-25°C). |
| Shelf Life | Unlimited under appropriate conditions (except surface oxidation). |
| Stability Note | Stable under normal conditions; forms a passive oxide layer on the surface. |
11. PACKAGING OPTIONS
| Packaging Type | Quantity | Material |
|---|---|---|
| Coiled on Spools | 50 kg, 100 kg, 200 kg | Wound on spools, shrink wrap |
| Bundled Rods | 10 kg, 20 kg, 50 kg | Bundled, plastic wrap or boxes |
| Cut Lengths | 1 m, 2 m, 5 m | Boxed, plastic wrap |
12. TRANSPORT INFORMATION
| Parameter | Information |
|---|---|
| UN Number | Not classified (specific regulations apply for metal alloys) |
| Hazard Class | - |
| Packing Group | - |
| ADR/RID | Not regulated (except powder form) |
| IMDG | Not regulated (except powder form) |
| IATA | Not regulated (except powder form) |
| HS Code | 7605.19.00.00.00 (Aluminum wire) |
13. REGULATORY STATUS
| Region / Authority | Status |
|---|---|
| European Union (REACH) | Registered |
| Turkey (KKDIK) | Compliance required |
| TSCA (USA) | Registered |
| China | Registered; major production and export country |
14. OTHER NAMES AND SYNONYMS
| Name | Description |
|---|---|
| Aluminum Wire | Common name |
| Al Wire Ø9.5 / Ø12.5 | Diameter-based variants |
| High Purity Al Wire | Purity description |
| Al Feed Wire | Usage description |
| Pure Aluminum Wire | Common name |
| Alloy Wire Additive | Usage description |
| Wire Form Aluminum | Descriptive name |
15. QUICK REFERENCE TABLE
| Property | Value |
|---|---|
| Aluminum Purity | ≥ 99.5% |
| Density | ~2.7 g/cm³ |
| Melting Point | ~660 °C |
| Diameter Options | Ø9.5 mm, Ø12.5 mm |
| Physical Form | Wire (Coil or cut lengths) |
| HS Code | 7605.19.00.00.00 |
| GHS Signal Word | WARNING |
16. CRITICAL WARNINGS AND BEST PRACTICES
CRITICAL WARNINGS:
-
High Purity: Aluminum feed wire is produced with minimum 99.5% purity. Lower purity may cause unwanted impurities in the final alloy.
-
Diameter Precision: Diameter tolerance is critical in automatic feeding systems. Ø9.5 mm and Ø12.5 mm are standard diameters with ±0.1 mm tolerance.
-
Quality and Origin: Purity and diameter precision in wire form are critical for automatic dosing and alloy accuracy. Trader-sourced products may show variability in origin and packaging.
-
Oxidation: Oxidizes in oxidizing atmospheres at high temperatures; inert atmosphere or vacuum is required for melting operations.
-
Acid Reactivity: Reacts with strong acids releasing hydrogen gas.
BEST PRACTICE RECOMMENDATIONS:
-
Storage:
-
Store in a cool, dry, and well-ventilated area.
-
Store in original packaging, moisture-free environment.
-
Keep away from acids and oxidizing agents.
-
Store at room temperature (15-25°C).
-
-
Handling:
-
Use in accordance with manufacturer's instructions in automatic wire feeding systems.
-
Handle carefully to prevent wire breakage or deformation.
-
Use vacuum or inert atmosphere (Ar, N₂) for melting operations.
-
Wash hands thoroughly after handling.
-
-
Waste Management:
-
Dispose of in accordance with local regulations.
-
Do not discharge into water sources.
-
For large quantities, aluminum recovery should be considered.
-
LEGAL DISCLAIMER
This Technical Data Sheet (TDS) is for informational purposes only and has been prepared based on available technical data. The user is solely responsible for determining the suitability of the product for their specific applications and for complying with all local, national, and international regulations. For complete safety, storage, handling, transport, disposal, and regulatory compliance information, the official Safety Data Sheet (SDS/MSDS) provided by the manufacturer/supplier must be consulted. This document does not substitute professional advice. Aluminum feed wire is a critical material for controlled aluminum addition in alloy production; correct diameter and purity selection directly affect final alloy quality.
