Send Email✓ Print Speed: 560m²/h
✓ Printing Width: 2.1m & 3.2m
✓ Only Non-Elastic Fabrics: Cotton, Polyster, Poly-Cotton, Nylon, Silk, Viscose, Linen,Denim Etc.
✓ Application Areas: Fabrics, Bed-Sheets, Curtains, Dresses, Bags, Pillows, Furniture, Upholstery, Custom Etc.
Technical Specifications
| Default Printhead |
Konica Minolta |
| Variable Drop | 6pl - 73pl |
| Printhead Options | 4 / 6 / 8 / 12 / 16 (max 2 rows) |
| Color Options | 4 color - 6 color - 8 color |
|
Ink Compatibility |
Disperse / Sublimation / Reactive / Pigment / Acid |
| Ink Tank System | Open System - 5kg capacity |
| Printing Width | 2.1m & 3.2m |
|
Media Type |
Elastic and non-elastic textiles |
|
Media Drying System |
Industrial Drying System |
|
Media Feeding System |
Included Feeding System |
|
Max Media Weight |
250 kg / 45 cm diameter |
|
RIP Software |
Neo-Stampa Optimum Digital Special Edition |
|
Graphical User Interface (GUI) |
ODP Print 2 |
|
Power Requirement |
Single Phase: 220 VAC / 25A (for machine) |
|
Printer Dimensions |
5500 mm x 2700 mm x 1500 mm |
|
Compressed Air |
0,6 MPa @ 2L / min |
|
Net Printer Weight |
2800 kg |
|
Net Machinery Weight |
3500 kg |
